Bobcat T450 specifications
Compact track loader · Historical T450 archive variants
Documented applicability
- Documented market
- North America (English manufacturer page); country-specific and serial applicability not established.
- Model years
- Not established
- Serial range
- Not established
- Evidence
Key facts
Published unit pairs take precedence. Calculated equivalents are marked approximate; unspecified gallon and horsepower definitions stay as published.
Metric display selected.
- Operating weightConflicting
Conflicting evidence. Bobcat publishes 6424 lbs in US view and 2019 kg in Metric view for the same column. These are incompatible weights; no authoritative value is selected.
- 2,914 kgApproximate conversionOperating Weight
- 2,019 kgPublishedOperating Weight
- Machine width
1,397 mmPublished
Column 1: T450. Overall machine width; bucket width is a separate source row.
Details and evidence for machine width- Engine power
41 kWPublished
Column 1: T450. Gross/net basis and horsepower definition are not stated; published values are retained.
Details and evidence for engine power- Rated operating capacityUnresolved
Applicability unresolved. Published variants or rating rows differ; select the relevant source column and configuration. No single value is selected.
- 676 kgPublishedROC Solid Undercarriage
- 745 kgPublishedRated Operating Capacity 200 lb. Counterweight
- 676 kgPublishedRated Operating Capacity
- Tipping loadUnresolved
Applicability unresolved. Published variants or rating rows differ; select the relevant source column and configuration. No single value is selected.
- 1,931 kgPublishedTipping Load
- 1,931 kgPublishedTip Solid Undercarriage
- Standard hydraulic flow
63.2 L/minPublished
Column 1: T450. Standard auxiliary flow. Gallon definition is unspecified; published unit pairs are retained.
Details and evidence for standard hydraulic flow
Detailed specifications
Each row keeps its manufacturer label and configuration. Separate rows do not define one combined machine configuration.
Conflicting evidence · Bobcat publishes 6424 lbs in US view and 2019 kg in Metric view for the same column. These are incompatible weights; no authoritative value is selected.
| Observation and evidence | Value |
|---|---|
Operating Weight Column 1: T450. Included equipment is not specified in this row. US view; conflicts with the other unit view of this same source row. Published: 6424 lbs | 2,914 kgApproximate conversion |
Operating Weight Column 1: T450. Included equipment is not specified in this row. Metric view; conflicts with the other unit view of this same source row. Published: 2019 kg | 2,019 kgPublished |
Source-supported
| Observation and evidence | Value |
|---|---|
Overall Width Column 1: T450. Overall machine width; bucket width is a separate source row. Published: 55 in / 1397 mm | 1,397 mmPublished |
Source-supported
| Observation and evidence | Value |
|---|---|
Overall Height Column 1: T450. Overall height; not raised-arm height. Published: 77.8 in / 1976.1 mm | 1,976.1 mmPublished |
Source-supported
| Observation and evidence | Value |
|---|---|
Length with Standard Bucket Column 1: T450. With standard bucket. Published: 126.6 in / 3215.6 mm Dimensions · Length with Standard Bucket · US and Metric; Column 1: T450 | 3,215.6 mmPublished |
Source-supported
| Observation and evidence | Value |
|---|---|
Length without Attachment Column 1: T450. Without attachment. Published: 98.4 in / 2499.4 mm Dimensions · Length without Attachment · US and Metric; Column 1: T450 | 2,499.4 mmPublished |
Source-supported
| Observation and evidence | Value |
|---|---|
Horsepower Column 1: T450. Gross/net basis and horsepower definition are not stated; published values are retained. Published: 55 hp / 41 kw T450 Key Specifications · Horsepower · US and Metric; Column 1: T450 | 41 kWPublished |
Applicability unresolved · Published variants or rating rows differ; select the relevant source column and configuration. No single value is selected.
| Observation and evidence | Value |
|---|---|
ROC Solid Undercarriage Column 1: T450. Rating percentage and the relationship between generic, undercarriage and counterweight rows are not established by this table. Published: 1490 lbs / 676 kg Performance · ROC Solid Undercarriage · US and Metric; Column 1: T450 | 676 kgPublished |
Rated Operating Capacity 200 lb. Counterweight Column 1: T450. Rating percentage and the relationship between generic, undercarriage and counterweight rows are not established by this table. Published: 1656 lbs / 745 kg Performance · Rated Operating Capacity 200 lb. Counterweight · US and Metric; Column 1: T450 | 745 kgPublished |
Rated Operating Capacity Column 1: T450. Rating percentage and the relationship between generic, undercarriage and counterweight rows are not established by this table. Published: 1490 lbs / 676 kg Performance · Rated Operating Capacity · US and Metric; Column 1: T450 | 676 kgPublished |
Applicability unresolved · Published variants or rating rows differ; select the relevant source column and configuration. No single value is selected.
| Observation and evidence | Value |
|---|---|
Tipping Load Column 1: T450. Undercarriage applies only where named in the row; generic and undercarriage rows are not assumed interchangeable. Published: 4257 lbs / 1931 kg | 1,931 kgPublished |
Tip Solid Undercarriage Column 1: T450. Undercarriage applies only where named in the row; generic and undercarriage rows are not assumed interchangeable. This row appears only in Metric view. Published: 1931 kg Performance · Tip Solid Undercarriage · Metric; Column 1: T450 | 1,931 kgPublished |
Source-supported
| Observation and evidence | Value |
|---|---|
Auxiliary Std Flow Column 1: T450. Standard auxiliary flow. Gallon definition is unspecified; published unit pairs are retained. Published: 16.7 gpm / 63.2 l/min Hydraulic System · Auxiliary Std Flow · US and Metric; Column 1: T450 | 63.2 L/minPublished |
Not stated in the reviewed source · Not stated in the inspected views: No matching specification row in US or Metric view.
| Observation and evidence | Value |
|---|---|
| Not stated in the inspected views: No matching specification row in US or Metric view. | Not available |
Source-supported
| Observation and evidence | Value |
|---|---|
System Relief @ Quick Couplers Column 1: T450. Pressure basis and hydraulic configuration follow the row label; published rounding is retained. Published: 3250 psi / 22408 kPa Hydraulic System · System Relief @ Quick Couplers · US and Metric; Column 1: T450 | 22,408 kPaPublished |
Configuration and source notes
- Historical T450 archive only; the current T450 Classic is outside this record.
- The source gives 6424 lbs and 2019 kg for operating weight. These disagree substantially; neither is selected as authoritative.
- No high-flow specification is stated in either inspected view.
- Source columns, left to right: Column 1: T450.
- Identical values are grouped only when the source row and both published unit strings agree; all contributing columns remain identified. Blank cells mean not stated, never zero.
- Specifications are for comparison and may include engineering calculations. Individual equipment varies; no verified serial range or complete model-year range is established.
Manufacturer sources
- Bobcat Company: T450 Compact Track Loader (Non-Current Model)
Edition / publication date not stated. · Inspected .
Inspected directly in a browser in US and Metric views. Source column identity and blank cells retained.
No complete model-year range or serial mapping is established.
Record reviewed by Codex (AI-assisted review; no independent human review). Transcription and second comparison of every in-scope value and source column against browser-captured manufacturer tables in US and Metric views; applicability limitations retained.
